TECHNICAL PARAMETER

Product Specifications

L*W*W (mm)

6055*2990*2896 (inside 5845*2780*2550)

Roof Form

Flat roof, organized internal drainage

Floor

≤3 floors

Design Parameters

Sevice Life

20 year

Ground Live Load

2.0KN/㎡

Roof Live Load

1.0KN/㎡

Wind Load

0.6KN/㎡

Seismic Fortification Intensity

8 Degree

Structure

Corner Post

Specifications: 210*150mm, galvanized cold-rolled steel, t=3.0mm

Corner Pieces

Top corner piece: length 210mm*width 150mm*height 200mm, bottom corner piece: length 210mm*width 150mm*height 165mm

Roof Main Beam

Specifications: 180mm, galvanized cold-rolled steel, t=2.5mm

Roof Secondary Beams

Specifications: C100*40*12*1.4*7 pieces, cold-formed thin-walled C-shaped steel, t=1.4mm

Ground Main Beam

Specifications: 160mm, galvanized cold-rolled steel, t=3.0mm

Ground Sub-beam

Specifications: 205*120 type beam, 1mm thick

Srap Plastic

Spray paint ≥80μm

Roof

Roof Panel

0.476 (0.40mm-0.41mm) thick color coated plate, white gray or beige color, 360 degree bite

Thermal Insulation Cotton

50mm thick glass wool felt, with aluminum foil on one side, bulk density 14kg/m³, combustion performance is A1 level non-combustible

Ceiling Panel

0.426 (foot 0.37mm-0.38mm) thick pressed galvanized plate, hidden nails, color white gray

Ground

Decorative Surface

1.6mm thick PVC floor, light gray

Substrate

18mm thick cement fiber board, density ≥1.3g/cm³

Wall

Thickness

75mm thick color-coated rock wool sandwich panel; the outer panel is made of 0.426 (0.37mm-0.38mm) color-coated board, the color is white gray or Ivory white, the inner panel is made of 0.376 (0.33mm-0.34mm) color-coated sheet, the color is white gray, the outer panel can be pressed with orange peel or Use a tablet.

Insulation

75mm thick rock wool, bulk density 80kg/m³, combustion performance is A1 level non-combustible

Door

Specifications (mm)

W850*H2030

Material

High-end steel door type A

Window

Specifications (mm)

Front window: W1150*H1100; rear window: W1150*H1100

Material

75 series plastic steel window, insulated glass, including anti-theft rod and screen window

Electricity

Distribution box

1 concealed electrical box

Voltage

220V~250V

Electric Wire

The total power cord at the entrance is 3*6.0 square meters, the air conditioning line is 3*4.0 square meters, the socket cord is 3*2.5 square meters, and the lighting switch cord is 2*1.5 square meters.

Circuit Breaker

High breaking miniature circuit breaker

Lighting

2 sets of double-tube LED fluorescent lamps, 40W/set

Socket

4 five-hole sockets 10A, 1 three-hole air conditioning socket 16A, 1 single switch 10A, national standard.

Industrial plug

220V,50Hz,3P32A

Other

Standard box inner corner package

0.426 (foot 0.37mm-0.38mm) thick color coated rolled and folded parts, color white gray

Aisle boxes, connecting boxes and packages

0.526 (foot 0.47mm-0.48mm) thick color coated rolled and folded parts, color white gray

Baseboard

Imitation wood grain PVC skirting

Adopt standardized construction and use equipment and accessories that meet national standards.

FAQ

Q 1. What foundation options are available for shipping container homes?

A

Our preferred general contractor can help you find and install the right foundation for your container home. The most important element of a container home foundation is that the ground is level. If it is level, a container home can be set there. With that said, we recommend using one of these foundation options:Railroad ties - this is often the least expensive option that can be used as a permanent foundation, and is the ideal option if you would like to move your container home some time in the future.Gravel pads - this option won't break the bank and is considered a long term, reliable, foundation for container homes.Concrete slab - this is often the most expensive option but also the most air tight when it comes to keeping your container home level and in place.
Q 2. Do you provide products to individuals only or do you also sell to businesses?

A

We sell our products to all markets and industries, including residential, commercial, industrial and governmental. We have the experience and capacity to partner with businesses on any type of container related project, large and small.
Q 3. What is the difference between a custom build and standard model?

A

Custom BuildsWe will craft a custom container home specific to your unique needs and location. Using a combination of stacked or adjoined 20ft and 40ft containers, we will create your dream home. We design our container homes to maximize the views and features of your property. We can incorporate just about anything into our container homes. We’ve built workshops, done a putting green, made a large rooftop garden, built custom furniture, and more.Standard ModelOur Standard container models are inspired by our most popular custom builds. Purchasing a standard container option from our website is the quickest and most affordable way to get your Backcountry Container, as it reduces a lot of the lead times and indirect costs that go into building a fully custom container home structure. Same quality, better price, delivered to you.
Q 4. Are there any extra costs or fees?

A

Yes, shipping fee.Shipping - Shipping fees for all builds depend on the distance from our build site (either in the Texas or Wisconsin area). Shipping typically costs around $3 per mile. Delivery for all builds will be quoted at time of purchase. For delivery, we must be able to drive our flatbed, tiltbed or chassis to the site to be unloaded.
Q 5. Will the metal rust on a container house?

A

The short answer is Yes. Color steel will rust much slower than mild steel, and will remain water proof through its lifetime. Color steel containers are corrosion resistant. Added layers of rust resistant paint and primer provides extra support.
